參數/Parameters

Specifications (Flat-Top)

單位/Unit

Min.

Max.

通道數/Number of Channels

96

CH

監控端波長Monitor Wavelength

1260~1620

nm

通道間隔/Number Channel Spacing

50

GHz

中心波長帶寬/Center Wavelength Channel Passband

± 0.05

nm

波長精度/Wavelength Accuracy

±0.04

nm

ITU頻率/ITU Frequency

196.10

191.35

THz

ITU波長/ITU Wavelength

1528.773

1566.723

nm

1dB帶寬/1dB Channel Bandwidth

0.18

nm

3dB帶寬/3dB Channel Bandwidth

0.28

nm

20dB帶寬/20dB Channel Bandwidth

0.7

nm

通道插損/Insertion Loss

7.0

dB

平坦度/Ripple

0.7

dB

通道一致性/Uniformity

1.5

dB

相鄰?fù)ǖ栏綦x度/Adjacent Channel Isolation

25

dB

非相鄰?fù)ǖ栏綦x度/Non-Adjacent, Channel Isolation

30

dB

總串?dāng)_/ Total Crosstalk

20

dB

方向性/Directivity

40

dB

回?fù)p/Return loss

40

dB

偏振相關損耗/Polarization Dependent Loss

0.5

dB

偏振模式色散Polarization Mode Dispersion

1.0

ps

色度色散/Chromatic Dispersion

-35

+35

ps/nm

最大輸入光功率/Maximum Input Power

23

dBm

工作溫度/Operating Temperature

-5

+65

℃

儲存溫度/Storage Temperature

-40

+85

℃

光纖類型/Fiber Type

G657.A1

/

連接頭/Connector

LC/UPC

/

封裝尺寸/Package size

120X70X10

mm

AWG

X

XX

X

XXX

X

X

X

XX

Band

Number of Channels

Spacing

1st Channel

Filter Shape

Package

Fiber Length

In/Out Connector

C=C-Band

L=L-Band

D=C+L-Band

X=Customize

16=16-CH

30=30-CH

40=40-CH

48=48-CH

XX=Special

1=100G

2=200G

5=50G

X=Special

C60=C60

H59=H59

C59=C59

H58=H58

XXX=special

G=Gaussian

F=Flat Top

M=Module

R=Rack

X=Special

1=0.5m

2=1m

3=1.5m

4=2m

5=2.5m

6=3m

S=Specify

0=None

1=FC/APC

2=FC/PC

3=SC/APC

4=SC/PC

5=LC/APC

6=LC/PC

7=ST/UPC

S=Specify
